LCD Display with FPC Connector for Saab 9-3 & 9-5 Sid1 / Sid2 / Sid3(with carbon ribbon cable)

Rating:
100% of 100

SA1001-4 is lcd with carbon ribbon cable. Application: Information Center Make/Model : Saab 9-3 & 9-5 Sid1 / Sid2 / Sid3 (1998-2002) Need heat bonding machine to mount on PCB

was US$43.80 Special Price US$19.04
Availability: In stock
SKU
SA1001-4
P.NO
1200100103
Quantity(Pcs)Unit Price(US$)
1+19.04
10+15.74

For more quantity price, please contact our customer service.

Application&Models

LCD Display With FPC Connector For Saab 9-3 & 9-5 Sid1 / Sid2 / Sid3

Application

Information Center

Model

Saab 9-3 & 9-5 Sid1 / Sid2 / Sid3 (1998-2002)

Specifications

Item Number SA1001-4
Dimension 152.0*34.1*3.3mm
Connect Type Heat Seal
Connector Type FPC
Applied Position Information Center
Storage Temperature  -30℃ to 80℃
Operation Temperature -20℃ to 70℃
Warranty  2 years

Features

1. Fully meet the OE specifications and perfect fit the module.

2. Need heat bonding machine to mount on PCB,  carbon track, easy to bond.

3. Same contrast as SA1001, Heatseal is thinner than SA1001.

4. 100% Brand New product and tested prior to leaving the factory.

Comparison between SA1001-4 and SA1001 are as below.

*SA1001-4 is lcd with carbon ribbon cable, while SA1001 is with silver ribbon cable;

*That means SA1001-4 is easier to be mounted to PCB, while SA1001 is harder to be mounted.

*You could use T-bar for soldering SA1001-4, but better use heat bonding machine to mount SA1001.

*The advantage of SA1001-4 is you could mount it easily, while that of SA1001 is that it has longer lifespan.
