G107 HELLA Garrett Turbo Actuator Gearbox 712120 6NW008412 For 742693-5004S 742693-9004S 742693-5003S 742693-5002 Turbocharger - SA1130-G107-H12

SA1130-G107-H12 Turbo Actuator Gearbox



The turbo actuator is part of a complete VGT turbo assembly manufactured by Garrett. The original turbo actuator has a short lifespan and therefore an extremely high failure rate. This actuator often cannot be purchased separately, and if it breaks, a complete turbo with the actuator assembly must be purchased. The high failure rate is primarily due to wear of the two plastic gears, which creates excessive friction and causes the DC motor to break. Since one of the gears causing this problem is laser-welded inside the gearbox, it is not possible to exchange just the plastic gears and the DC motor. Therefore, Sacer offers a remanufactured solution in the form of a completely new actuator gearbox. Completely new, patented, and easy to install.



Turbo Part Number:



742693-5004S 742693-9004S 742693-5003S 742693-5002



GARRETT No.:



712120



Hella No.:



6NW008412



Control Mode:



Version D (Digital/Intelligent)



For Brand:



Mercedes-Benz



For Model:



Mercedes-Benz E-Class 2002-2008



Mercedes-Benz C-Class 2000-2007



Mercedes-Benz M-Class 2005-2011



Advantages:



1. Independent software design



2. Includes independent PCBA design



3. Johnson Longlift DC motor



4. Transmission structure with special materials, good Wear resistance



5. The entire unit has passed high-speed aging tests (including durability, high and low temperatures, vibration, electromagnetic compatibility, etc.)



6. The angle can be customized through programming.



Warranty:



1-year warranty. 100% qualified testing and inspection before shipping.
