HELLA Garrett G226 Turbo Actuator Gearbox 712120 6NW008412 for 723341-0012, 723341-5012S, 723341-5013S and 723341-0013 Turbochargers - SA1130-G226-H66

SA1130-G226-H66 Turbo Actuator Gearbox



The turbo actuator is part of a complete VGT turbo assembly manufactured by Garrett. The original turbo actuator has a short lifespan and therefore an extremely high failure rate. This actuator often cannot be purchased separately, and if it breaks, a complete turbo with the actuator assembly must be purchased. The high failure rate is primarily due to wear of the two plastic gears, which creates excessive friction and causes the DC motor to break. Since one of the gears causing this problem is laser-welded inside the gearbox, it is not possible to simply swap the plastic gears and the DC motor. Therefore, Sacer offers a remanufactured solution in the form of a completely new actuator gearbox. Completely new, patented, and easy to install.



Turbo Part Number:



723341-0012 723341-5012S 723341-5013S 723341-0013



GARRETT No.:



712120



Hella No.:



6NW008412



Control Mode:



Version D (Digital/Intelligent)



For:



Peugeot



Citroën



For:



Peugeot 607 2000-2010



Citroën C6 2005-2012



Advantages:



1. Independent software design



2. Includes independent PCBA design



3. Johnson Longlift DC motor



4. Transmission structure with special materials, good wear resistance



5. The entire unit has passed aging tests High-speed (including durability, high and low temperatures, vibration, electromagnetic compatibility, etc.)



6. The angle can be customized through programming.



Warranty:



1-year warranty. 100% qualified testing and inspection before shipping.
