SA1160-sUTA-G13-H2 for Hella Turbo Actuator 6NW010430-02 797863-0013 for BMW 5 Series 2010->

TYPICAL APPLICATIONS



SACER SA1160-sUTA-G13-H2 intelligent electronic actuators are commonly used in Garrett VNT turbochargers (applications such as passenger car/light-duty diesel engines) to optimize performance and meet current and future emissions regulations.



No. G/No. 6NW



6NW010430-02



Garrett Turbo No.



797863-0013



Application:



GTB2056VZK; BMW N57TU Euro 6, N57N



Connector Position:



Middle



Features:



Lever angle tolerance: ≤ +/- 1.5 degrees; Lever backlash tolerance: ≤ +/- 1.75 degrees; Lever torque: ≥2.5 Nm; High-quality laser welding; Power supply: 14 V DC (Range: 10.5 V to 16 V); Operating temperature range: -40 °C to +125 °C; Storage temperature range: -40 °C to +150 °C



Quality Control



Full functional testing and confirmation of each unit. Full 1-year European warranty. Full functional testing, temperature testing, endurance testing, drop testing, vibration testing, salt spray testing, destructive testing, and EMC testing.
