SA1160-sUTA-G68 Electronic Turbo Actuator Repair for Hella (TBD) for Garrett 797863-0068

TYPICAL APPLICATIONS



SACER SA1160-sUTA-G68 intelligent electronic actuators are commonly used in Garrett VNT turbochargers (applications such as passenger car/light vehicle diesel engines) to provide optimal performance and meet current and future emissions regulations.



No. G/No. 6NW



To be determined



Garrett Turbo No.



797863-0068



Connector Position:



Middle



Features:



Lever angle tolerance: ≤ +/- 1.5 degrees. Lever free play tolerance: ≤ +/- 1.75 degrees. Lever movement torque: ≥ 2.5 Nm. High-quality laser welding. Power supply: 14 V DC (range: 10.5 V to 16 V). Operating temperature range: -40℃ to +125℃. Storage range: -40℃ to +150℃.



Quality Control



Full functional testing and confirmation of each unit. 1-year full European warranty. Full functional testing, temperature testing, endurance testing, drop testing, vibration testing, salt spray testing, destructive testing, and EMC testing.
