SA1160-sUTA-G70-H24 Electronic Turbo Actuator Repair for Hella 6NW010430-24 and Garrett 797863-0070

TYPICAL APPLICATIONS

SACER SA1160-sUTA-G70-H24 intelligent electronic actuators are commonly used in Garrett VNT turbochargers (applications such as passenger car/light vehicle diesel engines) to optimize performance and meet current and future emissions regulations.

No. G/No. 6NW

6NW010430-24

Garrett Turbo No.

797863-0070

Connector Position:

Middle

Features:

Lever angle tolerance: ≤ +/- 1.5 degrees. Lever free play tolerance: ≤ +/- 1.75 degrees. Lever torque: ≥ 2.5 Nm. High-quality laser welding. Power supply: 14 V DC (range: 10.5 V to 16 V). Operating temperature range: -40 °C to +125 °C. Storage temperature range: -40 °C to +150 °C.

Quality Control

Full functional testing and confirmation of each unit. 1-year full European warranty. Full functional, temperature, endurance, drop, vibration, salt spray, destructive, and EMC tests.

Warranty

RELIABILITY & PROVEN QUALITY

R&D Innovation Center

Advanced engineering team with 15+ years of turbo system expertise, utilizing CAD/CAE simulation and rapid prototyping for continuous product innovation.

Comprehensive Testing Lab

Full-spectrum validation including durability cycles, thermal shock (-40°C to +150°C), vibration resistance, and EMC compliance testing.

Quality Management System

IATF 16949:2016 & ISO 9001:2015 certified production with 100% incoming inspection, in-process monitoring, and final performance verification.

END-TO-END ACTUATOR SOLUTIONS

From application evaluation to global delivery, SACER provides reliable actuator solutions and services for OEM and aftermarket customers worldwide.

1

Product Identification & Model Matching

Based on the product information provided by the customer—such as OE number, turbocharger model, or product photos—we provide actuator model identification and matching services to help quickly find the correct replacement.

2

Flexible Customization & Quality Assurance

We provide flexible customization options supported by strict quality control and validation processes to ensure stable and reliable product performance.

3

Global Delivery & Technical Support

Our global logistics network and responsive technical support ensure efficient product delivery and long-term cooperation.

WARRANTY & AFTER-SALES SUPPORT

SACER provides full warranty and after-sales support. Download the official document below for details.

SACER Product Warranty & Service Terms.pdf

Click to download warranty documentation
