SA1160-UTA-G050-H24 Electronic Turbo Actuator Repair for Hella 6NW010099-24 and Garrett 797862-0050

TYPICAL APPLICATIONS



SACER SA1160-UTA-G050-H24 intelligent electronic actuators are commonly used for Garrett VNT turbochargers (applications such as passenger car/light-duty vehicle diesel engines) to provide optimal performance and comply with current and future exhaust emission standards.



No. G/No. 6NW



6NW010099-24



Garrett Turbo No.



797862-0050



Application



VM L630 Gen III



Connector Position



Center



Features



Lever Angle Tolerance ≤ +/- 1.5 degrees

Lever Backlash Tolerance ≤ +/- 1.75 degrees

Lever Torque ≥ 2.5 Nm

High-quality laser welding

Power Supply: DC 14V (range: 10.5V to 16V)

Temperature Range (Operating): -40℃ to +125℃

Temperature Range (Storage): -40℃ to +150℃



Quality Control



Fully functional testing and confirmation of each unit.



1-year full European warranty. Complete functional testing, temperature testing, endurance testing, drop testing, vibration testing, salt spray testing, destructive testing, and EMC testing.
