SA1160-UTA-G062-H24 Electronic Turbo Actuator Repair for Hella 6NW010099-24 and Garrett 797862-0062

TYPICAL APPLICATIONS



SACER SA1160-UTA-G062-H24 intelligent electronic actuators are commonly used for Garrett VNT turbochargers (applications such as passenger car/light-duty vehicle diesel engines) to provide optimal performance and meet current and future emissions standards.



No. G/No. 6NW



6NW010099-24



Garrett Turbo No.



797862-0062



Application



FCA Cento Giorgio Global WL



Connector Position



Medium



Features



Lever Angle Tolerance ≤ +/- 1.5 degrees

Lever Backlash Tolerance ≤ +/- 1.75 degrees

Lever Torque ≥ 2.5 Nm

High-quality laser welding

Power Supply: 14 V DC (Range: 10.5 V to 16 V)

Temperature Range (Operating): -40 °C to +125 °C

Temperature Range (Storage): -40 °C to +150 °C



Quality Control



Test and Confirmation Full functional testing of each unit.



1-year full European warranty. Full functional testing, temperature testing, endurance testing, drop testing, vibration testing, salt spray testing, destructive testing, and EMC testing.
