SA854 - Electronic video digital microscope with top light, eyelens and lcd monitor
| Camera | 480 (SONY chip) |
| eyelens | 0.5 time |
| objective lens | 0.7-4.5 time |
| Photo sourse | Fluorescence photo source |
| monitor | 8 inches,liquid crystal support |
Electronic video digital microscope with top light, eyelens and lcd monitor
Application
The applicable scope is very suitable for the electronics automotive industry. Camera: 480 (SONY chip), eyelens: 0.5 time, objective lens: 0.7-4.5 time, photo source: Fluorescence photo source, monitor: 8 inches, liquid crystal support.
Total enlargement factor: 7-150 times
resolution: 480 (sony chip)
resolution: 640x480
input voltage: 220V
output voltage: 12V
output mode: AV connection
color: colored; outward appearance
alloy outer covering, standard C connection
outward appearance size: 45*50*50MM
operating temperature: - 10-60 degrees
objective lens: 0.7-4.5 change time continuously
eyelens: 0.5X
fluctuation scope: 270mm
handwheel focusing scope: 65mm
center distance: 140mm
column diameter: 25mm
lens connection diameter: 50mm
support gross altitude: 355mm
foundation size: 390X270X28MM
net weight: 6KG.
