SA1018-3 - LCD DISPLAY with FPC and IC driver for Audi / VDO group

Rating:
100% of 100
Application: Instrument Cluster, dashboard Model: Audi A3 / A4 / A6 / TT / Jaeger Exceptions:The only different between SA1003-1 & SA1018-1 is the shape of FPC.
was US$24.00
You save: $4.79 (20% off )
Special Price US$19.21
Availability: Out of stock
SKU
SA1018-3
P.NO
1200202300
  • Buy 10 for US$15.89 each and save 17%
  • Buy 100 for US$12.71 each and save 34%

LCD Display With FPC And IC Driver For Audi / VDO Group

Application

Instrument Cluster / Dashboard

Model

Audi A3 / A4 / A6 / TT / Jaeger

Item Number SA1018-1
Glass Dimension 74.7*58.2*2.2mm
Connect Type Soldering
Connector Type FPC
Applied Position Instrument Cluster / Dashboard
Storage Temperature  -30℃ to 80℃
Operation Temperature -20℃ to 70℃
Warranty  2 years

1. Same TAB IC driver as OE. Need to clean the PIN from PCB side before soldering.

2. Normal soldering machine with very patient skills would be necessary.

3. If you could remove the OE IC driver from display well for resoldering process, Sacer could provide LCD display with FPC seperately for you.

4. Difference between SA1003-1 & SA1018: Same LCD display but different shape of FPC connector, compatible car models are also different.

5. 100% Brand New product and tested prior to leaving the factory.

Advantages

1. All new design, comparable to the original, perfect brightness, superior color.

2. Work well in the temperature of -20℃ to 70℃.

3. Full Function OQC test and confirm every piece is qualified.

4. Circuit protection design,  2 years European warranty.

Installation

If used in the JEAGER / MARELLI models, for soldering, as the picture shows, aligned and soldering the right pins, the left four pins do not need soldering.

LCD DISPLAY WITH FPC AND IC DRIVER FOR AUDI / VDO GROUP />
