Solenoid Valve For Compressor Air Suspension 9682022980 WABCO

For this item, we do not have any stocks for now, only batch booking is accepted.

NOTE: An air compressor assembly includes 3 solenoid valves: 2 pcs SA410 + 1 pcs SA411

NOTE: For this item, we do not have any stocks for now, only batch booking is accepted.

Application

Applied Area: It's used in compressor of air suspension system, to control the air piping to open or closed.

Troubleshooting: Original solenoid valve is easy to go bad, which ascribe to the poor corrosion resistance of the iron core. After working for a period of time, It gets so corroded that it is not able to fully block up the air piping, which finally leads to air leakage and air compressor malfunction.

Model

Citroen C4 Picasso (9682022980 WABCO) -- 2006-2013

Citroen Picasso Grand C4 (9682022980 WABCO) -- 2006-2013

OE Number

9682022980 / 415404830ZIE.5277E5 / 9682022980-00 / 9801906980 / 035 415 404 830 0

Item Number	SA410
Application	Air Suspension Compressor
Solenoid Type	Direct-acting
Ventilation Type	2-position 2-way
Matching Valve	SA411
Current	2.67 A
Resistance	4.6 Ω
Number Of Turns	600 ~ 610
Working Temperature	-40℃ ~ 85 ℃
Storage Temperature	0 ℃ ~ 40 ℃
Insulation Grade	H / 180 ℃
Switch Type	Normal Close
Coil Waterproof	The enameled wire insulated the water + Plastic package
Corrosion Resistance	Zinc Nickel Coating

Warranty

RELIABILITY & PROVEN QUALITY

R&D Innovation Center

Advanced engineering team with 15+ years of turbo system expertise, utilizing CAD/CAE simulation and rapid prototyping for continuous product innovation.

Comprehensive Testing Lab

Full-spectrum validation including durability cycles, thermal shock (-40°C to +150°C), vibration resistance, and EMC compliance testing.

Quality Management System

IATF 16949:2016 & ISO 9001:2015 certified production with 100% incoming inspection, in-process monitoring, and final performance verification.
