SA411 - Solenoid Valve For Compressor Air Suspension 9682022980 WABCO

Brand New Air Compressor Solenoid valve Application: Air Suspension Compressor Make / Model: Citroen C4 Picasso / Picasso Grand C4 OE: 9682022980 WABCO

US$0.00
Availability: Out of stock
SKU
SA411
P.NO
1040300200

Features

For this item, we do not have any stocks for now, only batch booking is accepted.

NOTE:  An air compressor assembly includes 3 solenoid valves: 2 pcs SA410 + 1 pcs SA411

NOTE:  For this item, we do not have any stocks for now, only batch booking is accepted.

Application

Applied Area: It's used in compressor of air suspension system, to control the air piping to open or closed.

Troubleshooting:  Original solenoid valve is easy to go bad, which ascribe to the poor corrosion resistance of the iron core. After working for a period of time, It gets so corroded that it is not able to fully block up the air piping, which finally leads to air leakage and air compressor malfunction.

Model

Citroen C4 Picasso (9682022980  WABCO)  -- 2006-2013

Citroen Picasso Grand C4 (9682022980  WABCO)  -- 2006-2013

OE Number

9682022980  /  415404830ZIE.5277E5 /  9682022980-00  /  9801906980  /  035 415 404 830 0



Item Number SA410
Application Air Suspension Compressor
Solenoid Type Direct-acting
Ventilation Type 2-position 2-way
Matching Valve  SA411
Current 2.67 A
Resistance  4.6 Ω
Number Of Turns 600 ~ 610
Working Temperature  -40℃ ~ 85 ℃
Storage Temperature  0 ℃ ~ 40 ℃
Insulation  Grade  H / 180 ℃
Switch Type Normal Close
Coil Waterproof The enameled wire insulated the water + Plastic package
 Corrosion Resistance Zinc Nickel Coating
Warranty  2 Years
