Turbo Electronic Actuator SA1182-2-12V- 06L145614B for Audi/VW EA888 Gen 3 2.0T inline-4 petrol

Product Details

SACER SA1182 Smart Electronic Actuator (SEA) is an advanced electromechanical wastegate actuator specifically designed for turbocharger systems on modern gasoline direct-injection engines (such as VW/Audi EA888 Gen3 1.8T & 2.0T platforms).

Unlike traditional pneumatic wastegates, the SACER SA1182 provides precise, closed-loop electronic control over the turbocharger wastegate position. The Engine Control Module (ECM) regulates the actuator's duty cycle using Pulse-Width Modulation (PWM) signals to adjust boost pressure continuously based on real-time engine operating conditions.

The ECM monitors parameter inputs—including engine speed, manifold absolute pressure (MAP / boost), desired fuel quantity, and atmospheric altitude—to command the SA1182 actuator. By rapidly adjusting the wastegate linkage, the actuator regulates exhaust gas flow bypassing the turbine wheel, preventing overboost, improving low-end throttle response, and enhancing fuel efficiency while reducing tailpipe emissions.

Key Features Include:

• High-Precision Wastegate Control: Ensures exact boost pressure regulation under all load and speed demands.
• Rapid Electronic Response: Eliminates turbo lag and provides seamless acceleration compared to traditional vacuum actuators.
• Emission & Efficiency Optimization: Supports optimal air-fuel ratio maintenance for improved fuel economy and reduced emissions.
• OEM-Grade Durability: Built to ISO9001 / IATF16949 standards with high-temperature electrical and mechanical components capable of enduring extreme under-hood thermal cycles.
• Direct Drop-In Replacement: Fully compatible with OE harness connectors and mounting interfaces for fast installation and precise ECU feedback.

Specifications

Notes

To ensure proper actuator replacement and reliable operation:

• Basic Setting / Voltage Calibration Required:

After mechanical installation, a diagnostic tool (such as ODIS, VCDS, or Launch) must be used to perform the "Basic Setting of Turbocharger Wastegate Actuator". The end-stop voltage must be adjusted on the rod according to OEM specifications (typically between 3.5V to 3.9V at rest/closed) to clear EPC codes.

• Inspect Wastegate Flapper Mechanism First:

Before mounting the new actuator, manually move the wastegate linkage on the turbine housing. Ensure the flapper opens and closes smoothly without sticking or excessive wear on the bushings.

• OE Part Number Verification:

If you are unsure whether this actuator matches your original turbocharger (IS12, IS20, or IS38), please provide clear photos of your turbocharger nameplate and original actuator label to SACER technical support before ordering.

APPLICATION

Engine

Audi/VW EA888 Gen 3 2.0T inline-4 petrol

Turbocharger NO.

06L145874E

Vehicle/Year

Audi A4 Sedan / Avant / Allroad (B9 Gen): 2016–2021

Audi A5 Coupe / Cabriolet / Sportback (B9 Gen): 2017–2021

Audi A6 Sedan / Avant (C8 Gen) & Audi A7 Sportback: 2018–2021

Audi S4 / S5 / S6 Lineups:

Audi Q5 (FY Gen) & Q7 (4M Gen): 2017–2022

Audi Q8 (4M Gen): 2019–2022

RELIABILITY & PROVEN QUALITY

1.R&D Innovation Center

Advanced engineering team with 18+ years of turbo system expertise, utilizing CAD/CAE simulation and rapid prototyping for continuous product innovation

2.Comprehensive Testing Lab

Full-spectrum validation including durability cycles, thermal shock  (-40°C to +150°C), vibration resistance, and EMC compliance testing

3.Quality Management System

IATF 16949:2016 & ISO 9001:2015 certified production with 100% incoming inspection, in-process monitoring, and final performance verification

END-TO-END ACTUATOR SOLUTIONS

From application evaluation to global delivery, SACER provides reliable actuator solutions and services for OEM and aftermarket customers worldwide.

1  Product Identification & Model Matching

Based on the product information provided by the customer—such as OE number, turbocharger model, or product photos—we provide actuator model identification and matching services to help quickly find the correct replacement.

2  Flexible Customization & Quality Assurance

We provide flexible customization options supported by strict quality control and validation processes to ensure stable and reliable product performance.

3  Global Delivery & Technical Support

Our global logistics network and responsive technical support ensure efficient product delivery and long-term cooperation.
